Our Facility
36,000 Square Foot Main Plant Machining Area
18,000 Square Foot Second Plant under a 5 Ton Overhead Crane for Assemblies
Both Facilities Adjacent on a Large 10 acre Lot
Complete Pipe Bending / Welding Cell in Operation in our Second Building Manufacturing Exhaust Systems
4,500 Square Foot Office with Company Training Area
Specializing in Machine Tool Component Parts: Shafts, Spindles, Wedges, Eccentrics, Assembly Pallets, Conveyors, Clamping Blocks, Bushings, Locators, Rings, Tubesheets, and Precision Details.
CNC Turning & Milling with 3D, 4th & 5th axis Capabilities
Numerous Years of Combined Experience Machining Exotic Alloys and Stainless Steels Resulting in a Vast Knowledge of Cutting Tool Capabilities
Stocked In-House Steel Room Allowing for Quick Turnarounds when Needed
In-House Heat Treating includes, Thru Hardening, Carb & Harden, Flame Hardening, Stress Relieving & Straightening
Complete In-House Grinding Department including: Blanchard, Surface, ID, OD, and two Moore #3 Jig Grinders in a Climate Controlled Room.
Fully Equipped Quality Assurance Lab with 3 Coordinate Measuring Machines.
ISO 9001-2008 Certified (since 1998)
Equipment List
Scroll down to see our equipment list or choose a department to jump to that section.
CNC Milling
Department
1 - Mazak 700E-II 50 Taper Vertical Mill
40 Tool Capacity with 28" X 84" Travel
Extended Table 88" long.
1 - Mazak VC-EZ 20 40 Taper Vertical Mill 2023
20" X 40" Travel. Setup for High Precision Finishing. Renishaw Probe
1 - Mazak VC-EZ 20 40 Taper Vertical Mill 2024
20" X 40" Travel. Also utilized for High Precision Finishing and Hard Milling.
1 - Mazak VTC 30 40 Taper Vertical Mill
30" X 64" Stationary Table Designed for Plate Style Work
1 - Mazak VTC 20 40 Taper Vertical Mill
20" X 44" Table with 10" Kitagawa 4th Axis Unit.
1 - Mazak VTC 20 40 Taper Vertical Mill
20" X 44" Travel.
1 - Mazak VTC 20 40 Taper Vertical Mill
20" X 44" Travel.
1 - Mazak 410A / HS 40 Taper Vertical Mill
16" X 32" Travel. High Speed Version 15,000rpm Spindle. 2000 IPM Rapid Traverse
1 - Fadal 6030 40 Taper Vertical Mill
30" X 60" Travel. Set up with Heavy Duty 4th Axis Rotary Table. 10,000rpm Spindle
1 - Mag Fadal 4525HT 40 Taper Vertical Mill
25" X 45" Travel. Set up with 4th & 5th Axis Rotary Table
1 - MAG MMH 500 Horizontal 40 Taper Machinig Center 2020
500MM Pallet Changing Table, B-Axis Full Contouring .001 degree, 15,000rpm Spindle
1- Mazak Nexus 530C-II 40 Taper Vertical Mill
21" X 42" Travel. 12,000rpm spindle, 1400 IMP Rapid Traverse
Thru Coolant 213psi / High Speed Tool Changer
2 - Technomagnete 20" X 30" High Performance Magnetic Milling Chucks
Modular Kaiser Boring System Years of investing into numerous Boring Heads and Modular components resulting in a very wide range of high precision boring capabilities.
Diameters Ranging from .125 to 9" Dia's with ability to bore up to .0002 tolerances.
CNC Turning
Department
1 - Mori-Seiki SL-45C CNC Lathe
19" Turning Diameter / 4.630" Thru Bore / 39" Turning Length
2 - Mori-Seiki SL-35B CNC Lathe
16" Turning Diameter / 3.630" Thru Bore / 32" Turning Length
1 - Mori Seiki SL-25 CNC Lathe Long Bed
12" Turning Diameter / 2.630" Thru Bore / 48" Turning Length
1 - Mori Seiki SL-25 CNC Lathe
12" Turning Diameter / 2.630" Thru Bore / 24" Turning Length
1 - Okuma Cadet
Collet Chuck 1-3/4" Diameter / Set up for very small precision parts
1 -Mazak Quick Turn Nexus 250
14" Turning Diameter / 3.000" Thru Bore / 20" Turning Length / 1200ipm Rapid
Tooling
Indexable Drills from .750" up to 3.000" Dia's
High Performance Drills from .375" to 1.125"
Extensive Groove Tooling Program (Face & OD)
Multiple Anti Vibration Bars for Deep Boring
Manual Turning
Department
1 - Kingston 22 X 80 Gap Bed Lathe
30" Capable with Gap out / 15" Precision Chuck / 4.06" Thru Bore / Newall DRO
24" 4 Jaw Chuck/Faceplate / Large Steady Rest 12" Dia. / Follower Rest / 1 Ton Crane
1 - Summit 19 X 80 Gap Bed Lathe
1 - Fischer 10" Speed Lathe
1 - Summit 17 X 80 Gap Bed Lathe
1 - Fischer Oil Grooving Machine
1 - Sydney Mach. 14 X 36 Gap Bed Lathe
1 - Leblond Regal 20 X 58 Gap Bed Lathe
Manual Milling
Department
1 - DeVlieg 3K-48 X 48
Equiped with Heidenhain .0001" Resolution Glass Scales &
30" X 30" DeVlieg Rotary Table
2 - CNC Ez-Trak Bridgeport Mills
1 - Summit VS-244 Vertical
6 - Bridgeport Mills
All w/ Digital Readouts & Power Feeds
1 - Heald #1 Horizontal
Surface Grinding
Department
1 - Blanchard 36" Table
1 - ELB Perfekt Grinder 25" X 45" 3 Axis NC
1 - Hammond 6" x 18"
1 - Okamato 16" X 32" Hyd. Wet Grinder
2 - B&S 510 5" X 10"
1 - Okamato 12" x 24" Hyd. Wet Grinder
1 - Parker 2SCM 6" X 18"
1 - Okamato 450G 6" X 18" Hyd. Grinder
1 - Mitsui 205MH 6" X 18"
ID & OD Grinding
Department
1 - DMG Mori, Vertical Mate 85 2021
Universal Vertical CNC Grinder
6 Tool Changer, up to 31.5" diameter and 23.6" tall
Renishaw Gaging probe, Machine is capable of 5 Micron tolerances
1 - Okamoto IGM-15NCII 2024
Twin Spindle CNC ID Grinding Machine
10,000 - 30,000 - 60,000 spindles on hand for various applications
1 - Yamada-Koki YIG-20M Automatic
1 -Heald 273A ID Grinder
1 -Heald 273A ID Grinder
3" Riser Plate w/ 18" Electromagnetic Chuck
1 - Toyoda 32 X 100 GUP 8GO
1 - Toyoda 32 X 100 GOP 9GO
1 - Cinn. 10" X 24" Plain
2 - Myford MG12HPM 5" X 12" 1 - Cinn. 12" X 36" Plain
Jig Grinding
& Honing
Department
2 - Moore #3 Jig Grinders
Completely Rebuilt by Moore
Housed in Climate Controlled Room
1 - Sunnen MBC 1804 Pwr. Stroke
1 - Sunnen MBC 1800 Pwr. Stroke
Tool Room
Equipment
2 - Sellers Mod 6G Drl. Point Gr.
1 - Gardner #5 Ped. Grinder
1 - Harig Steptool Universal
5 - Misc. Bench Grinders
1 - Cincinnati #2 Cutter Grinder
5 - Misc. Drill Presses
1 - Darex Drill Sharpener
1 - Hammond #14 Carbide Tool Gr.
1 - Darex End Mill Sharpener E85/90
1 - Cadillac Model 58 Roll Stamping Machine
1 - T D R Cutter Grinder
Heat Treating
Department
1 - Salt Bath 32" Deep Cap
1 - Trinco Glass Bead 48"
1 - Lindberg Homocarb 23 X 28
Carburizing furnace for "Carb & Harden"
1 - Wheelabrator 26" Wide
1 - Drake 150 Ton Elec. Press
2 - Lindburg Box Furnace 1200deg
1 - 15 Ton Straightening Press
1 - Despatch 24" x 24" x 40" Draw 1600deg
2 - 48" Centers for Straightening
2 - Wilson Rockwell Testers 30" X 60" Straightening Table
Quality Control
Department
1 - G & L Cordax RS-50 Bridge CMM
40" X 48" X 30" Envelope
TP20 Full DCC Rotating Head
PcDmis Software
1 - G & L Cordax Model 1808M - DCC MEA
24" X 24" X 40" Envelope
TP20 Manual Rotate Head
PcDmis Software
1 - Brown & Sharp MicroVal CMM
14" X 18" X 14" Envelope
1 - Gage Master 14" Optical Comparitor
1 - 4' X 8' Granite Surface Plate
5 - 24" X 36" Granite Surf. Plates
6 - 18" X 24" Granite Surf Plates
2 - 36" Mitutoyo Digital Height Gage
2 - 24" Mitutoyo Digital Height Gage
6 - 18" Mitutoyo Digital Height Gage
Multiple Bench Centers
Fully Climate Controlled
All Final Inspection Equipment calibrated to NIST Standards Annually
Sales Office
ECI JobBOSS² ERP System
Complete Shop Control Software / Full Financials / Inventory Mgmt. / Scheduling System
Barcoded Integrated / Live Job Status / Fully Electronic Payroll Clock In-Out
Running MS Office 365
72" touch screen setup for Zoom, Teams, Skype, etc
CAD/CAM
Department
3 - Seats MasterCam 2024
Full 3D w/ 4th & 5th Axis Programming
1 - Xpert DNC System
Fully Linked to all CNC Equipment
Complete Remote (At the Machine) -
Program Send / Receive / Inquire
Cloud Backed Up Program-Storage System Housing Proven-Programs Maintained & Controlled to the Rev. Level
Steel Room
Equipment
Large in-house stocked steel room, multiple grades of material on hand.
All color coded by grade and inventoried w/ Heat Numbers and Material Certs.
1 - W.F. Wells F-15 Band Saw 15 X 20
1 - W.F. Wells F-15-II Band Saw 15 X 20
